VCO is a fresh-coconut hygiene project before it is an oil press project

Fresh route

Keep fresh handling, milk pressing, and oil finishing in one clean chain

A VCO line should show the wet room, milk press, residue exit, warm oil tank, filtration point, and filling area as connected decisions. If one link is missing, the quote looks like a machine list instead of a product route.

Quote data

Data that makes a VCO route quoteable

• Raw coconut form: whole coconut, peeled kernel, crushed kernel, milk, or wet residue.
• Target products: VCO only, water plus VCO, milk plus VCO, or a retail coconut range.
• Hygiene level: clean room, wash water, drainage, warm storage, and food-contact expectations.
• Packing endpoint: jar, pouch, bottle, carton, private label, or bulk oil.

Project boundary

What to confirm before scoping Virgin Coconut Oil Route for Fresh Coconut Projects

Virgin Coconut Oil Route for Fresh Coconut Projects should not be quoted from an equipment name alone. Check feed lots, target oil, post-press handling, and packing rhythm in one scope before deciding which Coconut Oil Press modules stay. Coconut may be VCO on 355–500 cold, or a complete multi-product line (325 milk + 128 screw + refine).

When feed condition, moisture, impurities, batch weight, and product position are unclear, press tonnage and filter area become guesswork. Factory systems share 60 MPa and 2.2 kW motors; hot pure press is 30–40 min/barrel and cold pure press is ~2 h/barrel — cycle time matters more than brochure tonnage.

• Confirm whether feed is whole seed, kernels, pretreated material, or an existing semi-finished stream.
• Confirm whether the target is crude oil, filtered oil, bottled oil, drum ingredient oil, or a refining handoff.
• Hot cycle reference: pure press 30-40 min/barrel, ~1.5 h for 2 barrels with loading; cold pure press ~2 h/barrel, ~4.5 h for 2 barrels.
• Confirm batch rhythm, labor, changeover, retained samples, power (often 380V/50Hz/3ph), and site install conditions.

Factory model check

Match hot / cold models to factory hard data

Pin models to published factory specs before tonnage talk.

Hot 300/325: 300–325 ton, 60 MPa system, standard barrel Ø390×800 mm / max 100 kg, pure press 30–40 min/barrel, ~1.5 h for 2 barrels with loading, 2.2 kW motor. Cold 355/400/426/480/500: 370–630 ton, integrated frame, same 100 kg standard barrel, pure press ~2 h/barrel, ~4.5 h for 2 barrels with loading; optional Ø300 high-pressure barrel max 60 kg. Residual oil target ~≤5% (peanut hot often 6–8% measured).

• Standard barrel Ø390×800 mm, max ~100 kg crushed feed; optional Ø300 high-pressure barrel max ~60 kg.
• Cylinder material 27SiMn; cold frames are integrated molded steel; hot frames are typically H-type channel steel.
• Coconut may be VCO on 355–500 cold, or a complete multi-product line (325 milk + 128 screw + refine).

Equipment check

Coconut routes needs to land in equipment interfaces

Once the route is clear, write the interfaces: how preparation feeds the press, how oil leaves the press, how filtration connects to tanks, and how packing receives finished oil.
